Machine Elements: Analysis and Design

Machine Elements Analysis and Design 3rd edition

This book is intended to provide graduate and undergraduate students with basic understanding of machine element theory, and to introduce tools and techniques facilitating design calculations for a number of frequently encountered mechanical elements. The material in the book is appropriate for a course in Machine Elements and/or Mechanical Engineering Design for students who have passed first and second year basic courses in engineering physics, engineering mechanics and engineering materials science. At the end of each chapter in the book, references, which may be useful for further studies of specific subjects or for verification, are given.

NOTE: The exercise book for this is called Machine Elements Analysis and Design - Problems and it can be purchased separately.

Contents

Preface to the third edition Contents

1 Limits, fits and surface properties

1.1 Introduction

1.2 Geometrical tolerances

1.2.1 Specifying geometrical tolerances

1.2.2 Toleranced features

1.3 Surface texture

1.3.1 Surface Texture Parameters

1.4 Tolerances on lengths, diameters, angles

1.4.1 Dimensions and tolerances

1.4.2 Fits

1.4.3 Functional dimensioning

1.4.4 Dimension chains

1.5 The ISO-tolerance system

1.5.1 Introduction

1.5.2 Field of application

1.5.3 Terms and definitions

1.5.4 Tolerances and deviations

1.5.5 Preferred numbers

1.5.6 Standard tolerance grades IT1 to IT16

1.5.7 Formula for standard tolerances in grades IT5 to IT16

1.6 Nomenclature

1.7 References

2 Springs

2.1 Introduction

2.2 The design situation

2.3 Helical springs

2.3.1 Formulas for helical springs

2.3.2 Stress curvature correction factor

2.3.3 Material properties

2.3.4 Relaxation

2.3.5 Types of load

2.3.6 Dynamic loading

2.3.7 Compression springs

2.3.8 Extension springs

2.4 Belleville springs or coned-disc springs

2.4.1 Formulas for Belleville springs

2.5 Helical torsion springs

2.5.1 Methods of loading

2.5.2 Binding effects

2.5.3 Formulas for helical torsion springs

2.6 Spiral springs

2.6.1 Clamped outer end

2.6.2 Simply supported outer end

2.7 Supplementary literature

2.8 Nomenclature

2.9 References

3 Rolling element bearings

3.1 Introduction

3.2 Bearing types

3.2.1 Available space

3.2.2 Loads

3.2.3 Combined load

3.2.4 Misalignment

3.2.5 Speed

3.2.6 Stiffness

3.2.7 Axial displacement

3.3 Load carrying capacity and life

3.3.1 Basic load ratings

3.3.2 Life

3.3.3 Basic rating life equation

3.3.4 Requisite basic rating life

3.3.5 Adjusted rating life equation

3.3.6 Combination of life adjustment factors a2 and a3

3.3.7 SKF Life Theory

3.4 Calculation example

3.5 Calculation of dynamic bearing loads

3.5.1 Gear trains

3.5.2 Belt drives

3.5.3 Equivalent dynamic bearing load

3.5.4 Constant bearing load

3.5.5 Fluctuating bearing load

3.5.6 Requisite minimum load

3.6 Selecting static loaded bearing

3.6.1 Stationary bearing

3.6.2 Static load rating

3.6.3 Requisite basic static load rating

3.7 Radial location of bearings - Selection of fit

3.8 Bearing lubrication

3.9 Nomenclature

3.10 References

4 Shafts

4.1 Introduction

4.1.1 Terminology

4.2 Types of load

4.3 Shaft design considerations

4.3.1 Possible modes of failure

4.4 Static loading

4.5 Design for fatigue (cyclic load/dynamic load)

4.5.1 Stress concentration

4.5.2 S-N curve or Wöhler curve

4.5.3 Estimation of endurance level

4.5.4 Fluctuating load

4.6 Design for shaft deflections

4.7 Design for critical shaft speeds

4.8 Suggested design procedure, based on shaft yielding

4.9 Nomenclature

4.10 References

5 Shaft-hub Connections

5.1 Introduction

5.2 Positive connections

5.2.1 Pinned and taper-pinned joints

5.2.2 Parallel keys and Woodruff Keys

5.2.3 Splined joints

5.2.4 Prestressed shaft-hub connections

5.2.5 Failure of positive connections

5.3 Connection with force (Transmission by friction)

5.3.1 Cone interference fit

5.3.2 Interference fit with spacers

5.3.3 Interference fit (press and shrink fits)

5.4 Design modification/optimization

5.4.1 Spline design

5.5 Nomenclature

5.6 References

6 Threaded Fasteners

6.1 Introduction

6.2 Characteristics of screw motion

6.3 Types of thread

6.4 Types of bolts and nuts

6.5 Material specification for bolts and nuts

6.6 Force and torque to preload a bolt

6.7 Deflection in joints due to preload

6.8 Superposition of preload and working loads

6.9 Failure of bolted connections

6.10 Design modification/optimization

6.11 Nomenclature

6.12 References

7 Couplings and universal joints

7.1 Introduction to couplings

7.2 Functional characteristics

7.2.1 Shaft elongation or shaft division

7.2.2 Misaligned shafts or angular deviation

7.2.3 Man-operated engagement or disengagement

7.2.4 Torque-sensitive clutches

7.2.5 Speed-sensitive clutches

7.2.6 Directional (one-way) clutches, overrun clutches

7.3 Permanent torsionally stiff couplings

7.3.1 Rigid couplings

7.3.2 Universal joints and other special joints

7.4 Permanent elastic couplings

7.4.1 General purpose

7.4.2 Selection procedures

7.4.3 Damping

7.4.4 Max coupling torque for squirrel-cage motor

7.5 Overload couplings and safety couplings

7.6 Nomenclature

7.7 References

8 Clutches

8.1 Friction clutches

8.1.1 Torque transmission (static)

8.1.2 Transient slip in friction clutches during engagement

8.1.3 Dissipated energy in the clutch

8.1.4 Layout design of friction clutches

8.2 Automatic clutches

8.2.1 Speed-sensitive clutches (centrifugal clutches)

8.2.2 Directional (one-way) clutches. overrun clutches

8.3 Nomenclature

9 Brakes

9.1 Drum brakes

9.1.1 Self-energizing

9.1.2 Braking torque and friction radius

9.1.3 Wear and normal pressure for parallel guided shoe

9.1.4 Wear and normal pressure for non-pivoted long shoe

9.1.5 Wear and normal pressure for pivoted long shoe

9.2 Disc brakes

9.3 Cone brakes

9.3.1 Uniform pressure model

9.3.2 Uniform wear model

9.4 Band brakes

9.5 Nomenclature

10 Belt Drives

10.1 Introduction

10.1.1 Reasons for choosing belt drives

10.2 The belts

10.3 Belt drive geometry (kinematics)

10.4 Belt forces

10.4.1 Flat belt

10.4.2 V-belt

10.4.3 Including inertia

10.5 Belt stress (flat belt)

10.6 Optimization of belt-drives

10.7 Plot of the belt forces

10.8 Nomenclature

10.9 References

11 The geometry of involute gears

11.1 Introduction

11.2 Internal and external gears

11.3 Gear ratio

11.4 Gears in mesh

11.5 Tooth shapes

11.6 Involute tooth shape basics

11.7 Basic rack

11.8 Pitch and module

11.9 Under-cutting

11.10 Addendum modification (profile shift)

11.11 Tooth thickness

11.12 Calculating the addendum modification

11.13 Radial clearance

11.14 Gear radii

11.15 Contact ratio

11.16 Base tangent length

11.17 Helical gears

11.18 Nomenclature

11.19 References

12 The strength of involute gears

12.1 Introduction

12.2 General influence factors

12.2.1 Nominal tangential load, FNt

12.2.2 Application factor, KA

12.2.3 Dynamic factor, KV

12.3 Longitudinal (axial) load distribution factors, KHβ, KFβ

12.3.1 Principles of longitudinal load distributions

12.4 Transverse load distribution factors, KHα, KFα

12.4.1 Formulas for determination of factors

12.5 Calculation of surface durability (pitting)

12.5.1 Fundamental formulas

12.5.2 Allowable contact stress

12.5.3 Safety factor for contact stress (against pitting)

12.5.4 Zone factor

12.5.5 Elasticity factor

12.5.6 Contact ratio factor

12.5.7 Helix angle factor

12.5.8 Life factor

12.5.9 Lubrication factor

12.5.10 Roughness factor

12.5.11 Speed factor

12.5.12Work hardening factor

12.6 Calculation of load capacity (tooth breakage)

12.6.1 Fundamental formulas

12.6.2 Allowable tooth root stress

12.6.3 Safety factor for tooth root stress (against tooth breakage)

12.6.4 Tooth form factor

12.6.5 Helix angle factor

12.6.6 Life factor

12.6.7 Relative notch sensitivity factor, Yδ

12.6.8 Relative surface condition factor

12.6.9 Size factor

12.7 Elastohydrodynamic lubrication in gears

12.8 Design modification/optimization

12.9 Nomenclature

12.10 References

13 2D Joint Kinematics

13.1 Introduction

13.2 Joints in 2D

13.3 Degrees of freedom

13.4 Position, velocity and acceleration analysis

13.5 Mechanism design

13.6 Nomenclature

13.7 References

Appendix A: Tables with ISO-tolerances and fits

Appendix B: Stress concentration factors

B.1 References

Index
